PRADO TX-L 2.8L GD AT
|
PRAD VX 2.8L GD AT
|
PRADO VX 2.7L 2TR AT
|
| Major Dimensions and Vehicle Weights |
| Overall - length / width / height (mm) |
4840 / 1885 / 1890 |
4840/1885/1890 |
4840 / 1885 / 1890 |
| Tread - Front / Rear |
1585 / 1585 |
1585/1585 |
1585 / 1585 |
| Wheelbase (mm) |
2790 |
2790 |
2790 |
| Min Ground Clearance (mm) |
215 |
215 |
215 |
| Gross Vehicle Weight (Kg) |
2850 |
2850 |
2850 |
| Fuel tank capacity (L) |
87 |
87 |
87 |
| Min Turning Radius - Tire/Body (M) |
5.8 / 5.9 |
5.8/5.9 |
5.8 / 5.9 |
| Seat Capacity |
7 |
7 |
7 |
| Overhang- Front / Rear (mm) |
915 / 1215 |
915 / 1215 |
915 / 1215 |
| Angle of Departure |
25 |
25 |
25 |
| Angle of Approach |
31 |
31 |
31 |
| Chassis |
| Suspension Type (Front / Rear) |
Double wishbone / 4 link with lateral rod |
Double wishbone/4-Link with Lateral Rod |
Double wishbone / 4 Link with Coil spring |
| Transmission |
6-speed AT |
6-speed AT |
6-Speed AT |
| Brake Type (Front / Rear) |
Ventilated disc / Ventilated disc |
Ventilated disc / Ventilated disc |
Ventilated Disc / Ventilated Disc |
| Steering Gear Type |
Rack and Pinion |
Rack and Pinion |
Rack and Pinion |
| Tyres |
265/65R17 |
265/60R18 |
265/65R17 |
| Stabilizer bar (Front / Rear) |
Torsion bar: Front Rear |
Torsion bar: Front Rear |
Torsion bar: Front Rear |
| Engine |
| No of Cylinders |
4 cylinders, in-line type |
4-Cylinders, In-line type |
4 cylinders, in-line type |
| Valve Mechanism |
16-Valve, DOHC |
16-Valve, DOHC |
16-valve DOHC with Dual VVT-i |
| Displacement (cc) |
2755 |
2755 |
2694 |
| Fuel System |
Common rail type |
Common rail type |
EFI |
| Fuel Consumption (L/100Km) |
8.5 |
|
|
| Max Output (Kw/rpm) |
130/3400 |
130/3400 |
122/5200 |
| Max Torque (Nm/rpm) |
450/1600-2800 |
450/1600-2800 |
249/3900 |
| Fuel Type |
Diesel |
Diesel |
Petrol |
