PRADO Manual KD (Diesel)
|
PRADO Auto KD (Diesel)
|
PRADO Auto KD (Diesel - High Spec)
|
Major Dimensions and Vehicle Weights |
Overall - length / width / height (mm) |
4840 / 1885 / 1890 |
4840 / 1885 / 1890 |
4840/1885/1890 |
Tread - Front / Rear |
1585 / 1585 |
1585 / 1585 |
1585/1585 |
Wheelbase (mm) |
2790 |
2790 |
2790 |
Min Ground Clearance (mm) |
215 |
215 |
215 |
Gross Vehicle Weight (Kg) |
2850 |
2850 |
2850 |
Fuel tank capacity (L) |
87 |
87 |
87 |
Min Turning Radius - Tire/Body (M) |
5.8 / 5.9 |
5.8 / 5.9 |
5.8/5.9 |
Seat Capacity |
7 |
7 |
7 |
Overhang- Front / Rear (mm) |
915 / 1215 |
915 / 1215 |
915/1215 |
Angle of Departure |
25 |
25 |
25 |
Angle of Approach |
31 |
31 |
31 |
Chassis |
Suspension Type (Front / Rear) |
Double wishbone / 4 link with lateral rod |
Double wishbone / 4 link with lateral rod |
Double wishbone/4-Link with Lateral Rod |
Transmission |
6-speed MT |
5-speed AT |
5-speed AT |
Brake Type (Front / Rear) |
Ventilated disc / Ventilated disc |
Ventilated disc / Ventilated disc |
Ventilated disc / Ventilated disc |
Steering Gear Type |
Rack and Pinion |
Rack and Pinion |
Rack and Pinion |
Tyres |
265/65R17 |
265/65R17 |
265/65R17 |
Stabilizer bar (Front / Rear) |
Torsion bar: Front Rear |
Torsion bar: Front Rear |
Torsion bar: Front Rear |
Engine |
No of Cylinders |
4 cylinders, in-line type |
4 cylinders, in-line type |
4-Cylinders, In-line type |
Valve Mechanism |
16-Valve, DOHC |
16-Valve, DOHC |
16-Valve, DOHC |
Displacement (cc) |
2982 |
2982 |
2982 |
Fuel System |
Common rail type |
Common rail type |
Common rail type |
Fuel Consumption (L/100Km) |
9.1 |
8.5 |
8.5 |
Max Output (Kw/rpm) |
127/3400 |
127/3400 |
127/3400 |
Max Torque (Nm/rpm) |
410/1600-2800 |
410/1600-2800 |
410/1600-2800 |
Fuel Type |
Diesel |
Diesel |
Diesel |
